Residential PAK
The Residential PAK combines all of Sodimas’ expertise to deliver a complete solution for modernizing and renovating lifts.
It exceeds standard safety, environmental, and accessibility regulations, setting a new benchmark for performance and reliability.
Developed specifically for low-rise buildings, the Residential PAK ensures smooth operation, modern aesthetics, and long-term durability.
Equipped with the QI TOUCH control board featuring an integrated TFT touchscreen, and fully compatible with the latest EN 81-20/50 standards, it also includes the advanced FUJI 2 drive system — offering exceptional comfort, precision, and energy efficiency.
ELECTRICAL RENOVATION
The QI TOUCH control board features an integrated TFT touchscreen and is fully compatible with the latest EN 81-20/50 standards.
Paired with the advanced FUJI 2 drive system, it delivers exceptional performance, precision, and reliability — redefining comfort and control in modern lift technology.
- Mainboard QI touch with integrated tool – Conform to EN81-20 and 50 – Connectivity USB, Wifi, SD and compatible remote monitoring Sodi@com.
- Advanced Fuji frenic 2 – Asynchronous open loop or closed loop,
synchronous and multi-encoders – Integrated EMC filtering and energy saving mana- gement. - Limax positioning system by absolute real sensor control (without battery) and shaft encoded magnetic tape for millimeter resolution.
- Cop and landing fixtures according to EN81-70 with a programmable color TFT dis- play.
Single metal case with integrated drive, delivered with emergency recall operation, door position light, brackets, drawings.
- Car : Travelling cable plug and play , inspection box and pre-wired connection box, emergency power supply 12 vcc , siren, component cables , bracket and accessories.
- Machineroom : Main power supply cable, motor screen cable, components (gover- nor, brakes, ..) cables, plastic trucking and accessories.
- Shaft : Mixed wiring, for power security and control (Colors and numbers), plastic trucking, pit stop, braket and accessories.
POSITIONING
- Top of car embedded plug-in system with inox magnetic tape and came in shaft.
- Altitude by absolute sensor Limax.
- Final and inspection mechanical limit switch.
- Surface mounting range M3 : Cyntra black buttons – Blue led – Adjustable audio call record.
- COP : Stainless steel surface mounting 1060x220x35mm – Usb adjustable TFT color 4.3 inch display with voice announcer – Instructions.
- LOP : Stainless steel surface mounting 185x85x25mm.
- Landing display : Usb adjustable TFT color 3.5 inch display – Vertical or horizontal position by switch
Main features:
- Main power supply 3 phases 380/400V -50/60hz.
- Levels : 8 max.
- Speed : Up to 1 m/s
- Motor control inveinverter for Asynchronous open loop. – VVVF inverter power : Up to 11 kw / 24 amp.
- Entrance : 1 or 2 (same door operator type).
- Shortlevel: >30mm.
- Operation : Simplex sapb / down collective / full collective. – Car door : Automatic VVVF / master door.
- Brake power supply : 48 dvc / 110vdc / 220vac.
- Landing door : Automatic.
safety chain power supply : 110 vac.
Compatible options:
- Motor control : Close loop asynchronous / synchronous gearless.
- Encoder : Incrémental 5vcc / 12vcc- Absolute sin/cos or ENdat.
- Fireman operation.
- Car-door operation control operator by contactors.
- Manual landing door.
- Electrical retiring cam – Multi voltage.
- Multi voltage electrical brake.
- Pre-opening / relevelling.
- Governor remote control.
- Car / Motor fan.
- Automatic hall light switching.
- Existing push buttons (24 vcc – 1.2 w max).
Additional options:
- Sodimas COP / LOP and landing fixtures range.
- Additional electrical equipment (light curtain, shaft lighting, load weighting device, …).
- Additional mechanical equipment (frame, gearless, bedframe, doors, …).
